XLi Time & Frequency System 45
XLi-man, Issue 8, 6/17/2008, Rev. H
2
5
1
SSSSSSSSSSSS SSSSSSSSSS SSSSSSS S SSS S SSSSS S
5: Function Reference
Function Summary
The following summary lists all the XLi functions, identifies the user interfaces from which each one is
available, and provides a brief description of the function.
Available from: K = keypad, N = Network Port (Telnet), S = Serial Port, W = Web
Function
Available
From
Description
“F1 – Time Zone Offset”, page 48
K,N,S,W Set the time offset for Standard and Local time
“F2 – 12/24 Hour Format”, page 49
K,N,S,W Apply a 12 or 24-hour format to the Front Panel Display, to
F8, F9, and F90.
“F3 – Time & Date”, page 50
K,N,S,W Set the time and date (when not already provided by a
reference source)
“F4 – Serial Port Configuration”,
page 52
K,N,W Configure the main serial port settings
“F5 – Time-Quality Setup”, page 53
K,N,S,W Set the thresholds for each of the four time quality flags
“F6 – Keypad Lock”, page 55
K*,N,S Lock keypad access to the XLi’s functions. (When locked,
F6 is the only function available from the keypad.)
“F8 - Continuous Time Once-per-
Second”, page 56
N,S Output the time once-per-second (to the command line)
“F9 - Time On Request”, page 58
N,S Output the time when triggered (to the command line)
“F11 - Time Output Format”, page 59
N,S Change the format of the time output by F8 and F9
“F13 – Time Error”, page 61
K,N,S,W View the current estimated worst case time error
“F18 – Software Version Request”,
page 62
K,N,S,W View the XLi’s software version information
“F27 – FTM III Configuration”, page 63
K,N,S,W Manage the Frequency and Time Deviation Monitor card
“F42 – Multicode Output Configuration”,
page 69
K,N,S,W Set the time code type and time reference for specific ports
on the optional Multicode Output card(s)
“F44 – N.8 Frequency Synthesizer”,
page 73
K,N,S,W Set the frequencies generated by specific ports on the
optional N.8 Frequency Synthesizer card(s)
“F50 – GPS Receiver LLA/XYZ
Position”, page 75
K,N,S,W View the Latitude/Longitude/Altitude or geocentric X/Y/Z
coordinates of one or more GPS antennas.
“F51 – GPS Antenna Cable Delay”,
page 77
K,N,S,W Compensate for the delay caused by the length of the GPS
antenna cable. (Use F52 to adjust timing outputs.)
“F52 – Distribution Cable Delay”,
page 78
K,N,S,W Compensate for the length of the distribution cable on J2.
