152 XLi Time & Frequency System
XLi-man, Issue 8, 6/17/2008, Rev. H
SSSSSSSSSSSS SSSSSSSSSS SSSSSSS S SSS S SSSSS S
1
F118 – Option Board Configuration
Use function F118 to query the XLi for the option bay location of CPU-aware cards. The following figure
shows the position of the option bays as seen when viewing the XLi from the rear
.
Figure 8: Option Bay Positions
The cards recognized by F118 are as follows:
• N.1 Frequency Synthesizer (87-8022)
• GPS C/A Receiver (87-8028-2)
• Frequency and Time Deviation Monitor (87-8023)
•
HaveQuick/1 PPS Time and Frequency Reference(87-8016-3)
• Have Quick Output with selectable TFOM (87-8016-6)
• PTTI BCD Output (87-8045)
• Parallel BCD mSec Output with Time Quality (87-8090)
• Parallel BCD uSec with Time Quality (87-8090-1)
• Parallel BCD mSec Output with Unlock Status (87-8090-2)
• GPS Receiver (86-8013)
The cards not recognized by F118 are as follows:
• N.8 Frequency Synthesizer (86-708-1)
• Multicode Output (87-6002-XL1)
•
Low Phase Noise 5 MHz Output (87-8009-5)
• Low Phase Noise 10 MHz Output (87-8009-10)
• Enhanced Low Phase Noise Module (87-8040)
• 1, 5, 10 MHz Sine/MPPS Square Output (86-8008)
• T1 Telecom Interface Output (87-6000T1-8)
•
E1 Telecom Interface Output (87-6000E1-6)
Power Supply
Bay 4
Bay 3
Bay 2
Bay 1
XLi CPU Module
Opt. Power Supply
Bay 10
Bay 9
Bay 6
Bay 5
Power Supply
Bay 8
Bay 7
Bay 4
Bay 3
XLi CPU Module
Bay 2
Bay 1
2 U Chassis:
1 U Chassis:
