XLi Time & Frequency System 13
XLi-man, Issue 8, 6/17/2008, Rev. H
2
5
1
SSSSSSSSSSSS SSSSSSSSSS SSSSSSS S SSS S SSSSS S
OUTPUT:
• Amplitude (AM): 3 Vp-p ±10%, into 50
Ω
• Ratio (AM): 3:1 ±10%
•Qty: 1
• Connector: BNC female
• Phasing: In phase with the XLi 1PPS ± 10 us
Time Code Output IRIG-B000 w/ IEEE1344
The selectable Code output has an additional selection for IRIG-B-000 w/ IEEE1344, configuration is via
the Keypad / Display, RS232/422 and the Network port via telnet and HTML.
Table 1:
Binary Time
quality
Xli Estimated Time Error (ETE)
1111 Initial condition clock unlocked or 10Sec < ETE
1011 Clock unlocked and 1Sec < ETE <= 10Sec
1010 Clock unlocked and 100mSec < ETE <= 1Sec
1001 Clock unlocked and 10mSec < ETE <= 100mSec
1000 Clock unlocked and 1mSec < ETE <= 10mSec
0111 Clock unlocked and 100uSec < ETE <= 1mSec
0110 Clock unlocked and 10uSec < ETE <= 100uSec
0101 Clock unlocked and 1uSec < ETE <= 10uSec
0100 Clock unlocked and 100nSec < ETE <= 1uSec
0011 Clock unlocked and 10nSec < ETE <= 100nSec
0010 Clock unlocked and 1nSec < ETE <= 10nSec
0001 Clock unlocked and ETE <= 1nSec
0000 Clock locked to a reference source
