XLi Time & Frequency System 29
XLi-man, Issue 8, 6/17/2008, Rev. H
2
5
1
SSSSSSSSSSSS SSSSSSSSSS SSSSSSS S SSS S SSSSS S
Standard XLi
The standard XLi configuration comes with an AC Power supply and CPU module. The standard XLi
does not require
changes to its factory settings, which are as follows:
Additionally, the Standard XLi’s factory settings for F73 are as follows:
Description Setting Function & Cross Reference
J1 Configuration IRIG-B (120 AM)
“F110 – J1 Input (Time Code, TIET)” on
page 137
J1 Time Reference Primary
“F110 – J1 Input (Time Code, TIET)” on
page 137
J2 Rate Out 10 MPPS
“F111 – J2 Output (Rate, PPO)” on page 142
J3 Configuration Aux Ref Disabled
“F113 – J3 Input (Aux Ref, Freq Meas)” on
page 146
1 PPS 1 PPS – non configurable Non configurable
Code Output Format IRIG-B (120 AM)
“F90 – Code Output Configuration” on page 116
Reference Source PRI
“F74 – Clock Source Control” on page 107
Indicator/Parameter Name Factory Setting
PLL Locked Alarm Enabled
Low Phase Noise (LPN) PLL Locked Alarm Enabled
GPS Primary Receiver Alarm Disabled
GPS Secondary Receiver Alarm Disabled
IRIG Fault Alarm Enabled
Aux Ref Fault Alarm Disabled
Primary Power Alarm Enabled
Secondary Power Alarm Disabled
Rubidium oscillator (visible on display when Rb Osc is installed) Alarm Disabled
DAC Alarm Disabled
First Time Lock Alarm Enabled
Time Error Alarm Enabled
Time (Error) Threshold 0000 nS
Alarm LED Blink Alarm Enabled
Timeout Alarm Enabled
Timeout Delay 300 sec.
Power-On Alarm Suppress 300 sec.
NTP Alarm Enabled
