XLi Time & Frequency System 63
XLi-man, Issue 8, 6/17/2008, Rev. H
2
5
1
SSSSSSSSSSSS SSSSSSSSSS SSSSSSS S SSS S SSSSS S
F27 – FTM III Configuration
Use F27 to manage the Frequency and Time Deviation Monitor (87-8023) option card (page 192).
Keypad
The UP ARROW DOWN ARROW keys are used to scroll between the selections, and the ENTER key is
used to access the currently displayed selection (numeric keys are placed in <> brackets for clarity).
After accessing a particular selection, information can be entered by scrolling to a desired value via UP
ARROW and DOWN ARROW keys or by directly entering the desired value. The specific data entry
method is dependent upon the particular selection.
Pressing the TIME or STATUS keys aborts the keypad function without affecting the current entry value.
Operation of Keypad F27 is detailed in the following paragraphs.
Press ENTER <2> <7> to access the FTM. The front panel 2-line VFD displays the following title.
FTM Availability
OPTION BAY <N>
Use UP ARROW and DOWN ARROW to select an FTM, and press ENTER.
Time and Frequency Deviation Display
This display is only informational. ENTER to continue to the next display or CLR to begin again.
Time Deviation Offset Entry
This display shows the current preset value for time deviation offset. This value is set by the user and
does not change until changed by the user. Press UP to edit the value and/or reset the accumulated time
deviation.
UP followed by ENTER does not change the time deviation offset, but resets the accumulated time
deviation to that value. The four arrow keys and the numeric keys are used to edit the time deviation
offset entry. ENTER exits this display and steps to the next.
•Time Deviation
•Entry
• Front Panel
• VFD Setup
• Front Panel
• Display Port
• RS-422 Setup
• Display Port
• Data Addr Setup
