46 XLi Time & Frequency System
XLi-man, Issue 8, 6/17/2008, Rev. H
SSSSSSSSSSSS SSSSSSSSSS SSSSSSS S SSS S SSSSS S
1
“F53 – GPS Operation Mode”, page 80
K,N,S,W Operate specific GPS receivers in Auto Mode for static
applications, or in Dynamic Mode for mobile applications.
“F60 – GPS Receiver Satellite List”,
page 81
K,N,S,W View a list of current and tracked satellites.
“F66 – Daylight Saving Time (DST)
Mode”, page 84
K,N,S,W Schedule when DST starts and ends (Local time only)
“F67 - Manual Leap Second Entry”
K,N,S,W Manually schedule in section of leap seconds.
“F69 – Time Mode”, page 89
K,N,S,W Set the type of time (GPS, UTC, Standard, Local) displayed
on the front panel of the XLi
“F71 – Oscillator Statistics”, page 91
K,N,S,W Display the XLi oscillators phase, offset, drift, and DAC
values
“F72 – Fault Status”, page 92
K,N,S,W View clock and power supply fault status
“F73 – Alarm Control / Status”,
page 94
K,N,S,W View the status of all the alarm indicators. Enable/disable
alarms for each indicator. Set alarm thresholds. Enable or
disable LED blink
“F74 – Clock Source Control”,
page 107
K,N,S,W Select the pattern of switching between reference sources
“F77 - PTTI Output”
K,N,S,W Configure and display status of PTTI card.
“F78 - Parallel BCD Output”
K,N,S,W Configure and display status of Parallel BCD Output board.
“F90 – Code Output Configuration”,
page 116
K,N,S,W Configure settings for CODE – time code output
“F100 – Network Port Configuration &
XLi Firmware”, page 117
K,N,S,W Configure the standard network port settings
F100 EA – Ethernet Address
K,N,S,W Display the Ethernet (MAC) address
F100 IP – IP Address
K,N,S,W Configure the IP address
F100 SM – Subnet Mask
K,N,S,W Configure the subnet mask
F100 G – Gateway
K,N,S,W Configure the default gateway
F100 IC – Network Port Settings
K,N,S,W Display all the standard network port’s settings
F100 BASET – 10/100 BASE- T
K, N, S View network port setting
F100 L/LOCK/UNLOCK – Remote
Lockout
K,N,S Lock remote access to the XLi’s standard network port
F100 L – Remote Lockout
K,N*,S Display the status of F100 LOCK
*Locked through the network port, serial port, and keypad.
Can be unlocked only through the keypad or serial port.
F100 ST – Self Test Status
K,N,S Display the XLi’s self test results for Flash CRC, RAM,
Serial Port, and NVRAM
F100 BH – Burn Host
N,S*
b
Upgrading system firmware: select the FTP host, path, and
filename of the system firmware
F100 BUB – Burn BootLoader
N,S*
b
Upgrading system firmware: ‘burn’ the bootloader file (*.bt)
selected using F100 BH to flash memory
