To generate any other signal type, three steps are required. First, move the plug in JP2 to the DC jumper
(e.g., J4 DC). Second, select a signal type from the following table and note the corresponding switch
position (e.g., 10 MPPS = position 1). Finally, using a small flat-head screwdriver, turn the rotary switch
(e.g., S4) to the appropriate switch position (e.g., 1). In this example, the J4 output would be set to
generate 10 MPPS and the procedure would be complete. The same method can be used to configure
any of the outputs..
Note: PPO and Alarm are only available if those options have been purchased and are enabled using
F126 – Options Key Entry (page 164).
Switch Position Signal Type
0Off
1 10 MPPS
2 5 MPPS
3 1 MPPS
4 100 kPPS
5 10 kPPS
6 1 kPPS
7 1 PPS
8 Time Code DC
9 PPO
AAlarm
B-F Not Used
