The level under the xli group is divided into four groups; the first two of which will be explained later. The
optionCardGroup has all the available option cards under it. Under each option card is a table for that
option card type because there may be multiple cards of that type within an XLi chassis.
The current traps message group is located under the fault. The ntp group is under the xliMainCard
group as an option, and is related to only to NTP on the standard network port on the main XLi CPU
module. For each instance of an NTP option card
, the NTP group will be repeated under the optionCards
group. GPS is located under the optionCards group, and is repeated for each GPS option card. The
ntsControl and acts groups have not been implemented for the XLi.
This MIB structure also provides a useful definition for the system object ID. SNMP managers may use
the system object ID to identify the class of object being accessed. With this structure, the system object
ID is defined as Truetime.products.xli for the XLi product and Truetime.products.xxx for all subsequent
products.
TrueTimeEnt
= 1896
products
= 6
xli
= 1
xliSystem
= 1
xliMainCard
= 2
systemFault
= 1
ntp
= 1
systemStatus
=2
Additional
Products
xliOptionCards
= 3
Additional
Option
Cards
systemAlarmData
= 1
systemFault
Config
= 2
systemFault
History
= 3
systemStatus
General
= 1
systemStatus
Detail
= 2
xliTrap
= 0
