Tait TP9500 - LED Behavior

•Placejustabatteryinthecharger,oraradiowithabatteryattached(desktopchargeror6-waychargeronly).
Thereisnoneedtoremoveabeltclip,antenna,oranyaccessorythatisattachedtotheaccessoryconnector.
TheredLEDlightsupandstayslitwhilethebatterycharges.
Whenchargingiscomplete,thegreenLEDstayslit.
LED Behavior
Ifthereisabatteryinthechargerwhenpowerissuppliedtothecharger,theLEDsbehaveasfollows:
Meaning
(briefly)
Thechargerhasbeenconnectedtoapowersupply.
(steady)
Thebatteryischarging.
(steady)
Chargingcomplete.Removethebattery,orleaveitinthecharger.
(steady)
Thebatterytemperatureisoutsidethenormalchargingrange.Chargingwillstartor
resumeoncethetemperatureiswithinnormallimits.Noactionisrequiredbyyou.
Thereisafault.Contactyourdealer.
or
(flashing)
IftheLEDsforallchargerslotscontinuouslyflashorange,orredthenorange,thechar-
geritselfmaybefaulty(e.g.the6-waychargerfanmaybejammed).Contactyour
dealer.
(alloff)
Thereisafault.Contactyourdealer.
Ifthechargerdoesnotbehaveasexpected:
•Makesuretheradioorbatteryisseatedproperlyinthecharger.Forthevehiclecharger,seealsoInsertingthe
RadiointotheVehicleCharger.
•Checkthatthechargerisproperlypluggedintotheoriginallysuppliedpowersupply.
•Checkthatthebatteryandchargercontactsareclean.Toclean,wipethecontactswithadrylint-freeclothto
removeanydirt,oilorgrease.
