Tait TP9500 - Understanding the Radio Display; Radio display icons

Name
Function
Alphanumeric
keys
Usedtoenterlettersandnumbers
Understanding the Radio Display
Themessagesandiconsontheradiodisplaydependonthemodeinwhichtheradioisoperatingandthewayitispro-
grammed.
Radio display icons
Thesearesomeoftheiconsyoumayseeonyourradiodisplay:
Icon Meaning
Batteryindicator:showshowmuchchargeisavailableinthebattery
Scanning:yourradioismonitoringagroupofchannelsorworkgroupsforactivity
Silentoperation:yourradio’saudibletoneshavebeenturnedoff
Low-powertransmit:theradioistransmittinginlowpower
Transmit:theradioistransmitting
/
Automatic/Manualmode:automaticchannelorzoneselectionhasbeenturned
on/off
Headsetconnected:thereisawirelessheadsetconnectedtoyourradio
Flashing:yourradioisattemptingtoconnecttoaheadset,ortheheadsetcon-
nectionhasbeenlost
Scrambler:thevoice-inversionscrambleristurnedon(analogchannelsonly)
Signalstrengthindicator:themorebars,thestrongerthesignalbeingreceivedby
theradio
Scrolling:youcanuse or tomovethroughalist,oraccessa
pre-programmedmenu
Queuing:therearecallsormessagesinthequeue
