Status Indicators
Figure 3.1 Location of LED status indicator
Color  Meaning
Red
(transmit)
Glowing:theradioistransmitting
Flashing:thetransmittimerisabouttoexpire
Green
(receive)
Glowing:thecurrentchannelisbusy
Flashing:theradiohasreceivedacall(analogchannelonly)
Orange
(network)
Flashing:theradioisregisteredonatrunkednetwork
AllLEDs
off

Trunked:networknotavailable,ortheradioisattemptingtoregisteronatrunkednetwork
Conventional:receivestandby
Audible Tones
Theradiousesaudibletonestoalerttheusertoitsstatus:
•Radiocontrolsandkeypresstones—thetonesandbeepsthatareaudiblewhentheradio’skeysarepressedor
thecontrolsareused.
•Incomingcalltone—whentheradioisreceivingacall.
•Warningtones—whenthereisanerror,orthebatteryislow,forexample.
If quiet or silent mode is turned on, you will not hear any alert tones.
