Introduction
Thank you for purchasing the TD-9000T Digital Indicator.
Please read this document in its entirety before using the
product to get the best performance and ensure safe and
proper operation.
Features
o Five-digit digital display enables direct reading of physical
quantities.
o Waveforms can be checked in real time even when they are
being measured.
o Support for TEDS sensors makes calibration easy.
Automatic calibration is also possible when a TEDS sensor
is connected.
o An equivalent input function is included, making sensitivity
adjustment without actual loads easy.
o Supports remote sensing functions. Even using long cables
measurement is possible without losing precision.
o Static strain measurement is possible. Identifying load cell
defects and other problems through plastic deformity is easy.
o In addition to high and low limit comparison, this indicator
also supports high high limit and low low limit comparison
functions.
o Measurement is possible using combinations of band and
five zone judgments as desired.
Each zone supports a variety of judgments, including con-
stant comparison, sampling, peak, bottom, peak to peak,
average value, maximum/minimum and inflection point.
o DIN size supports incorporation with testing devices and
manufacturing equipment, for example.
o D/A output according to designated values is a standard
feature.
o Product complies with RoHS.
o Waveform display function allows input signals to be
checked as waveforms.
o Measurement data can be saved on SD cards and in the
built-in memory of the unit.
o Linearization function improves linearity of load measurements.
Included accessories
If anything is missing or damaged, contact us. (For contact
information, see the last page.)
SENSOR connector plug
B2CF 3.50/18/180LR SN OR BX 1
CONTROL connector plug
HDCB-37P (05) connector 1
HDC-CTH (4-40) (10) case 1
Power input terminal bank cover
(pre-installed on unit) 1
Disclaimers
Information is given about products in this manual only
for the purpose of example and does not indicate any
guarantees against infringements of third-party intellectual
property rights and other rights related to them. TEAC
Corporation will bear no responsibility for infringements on
third-party intellectual property rights or their occurrence
because of the use of these products.
SDHC Logo is a trademark of SD-3C, LLC.
TEAC is a trademark of TEAC CORPORATION, registered in the
U.S. and other countries.
Other company names, product names and logos in this
document are the trademarks or registered trademarks of their
respective owners.
