6-1-4. Unique communication protocols
This is an explanation of commands for communicating unique protocols.
In this section, examples of transmission using TD Format (BCC) are given.
To transmit using TD Format, remove the checksum from the transmission examples.
Example responses are only given for command execution results that have completed properly.
Response data values that are not fixed are given as "x" or data names, and symbols are given as "±".
6-1-4-1. Indicator value polling (0005)
If the measurement status of the unit is “Continue”, the status and current indicator value will be returned. If the measurement status
of the unit is anything else, only the status will be returned.
Command
HEX 0×23 0×30 0×30 0×30 0×30 0×30 0×35 0×32 0×35 0×0D 0×0A
ASCII # 0 0 0 0 0 5 2 5 CR LF
Fixed Command No. Checksum
Responses
When the measurement status of the unit is “Continue”, and the sensor settings Y axis setting is “LOAD & DISPLACE.” or the X axis set-
ting is “DISPLACE.”
Byte 0 1 2 3 4 5 6 7 8 9 10–16 17 18–24 25 26 27 28
HEX 0×06 0×30 0×30 0×30 0×30 0×30 0×35 0×2c 0×0D 0×0A
ASCII ACK 0 0 0 0 0 5 ST1 ST2 ST3 Load value ,
Displacement
value
× × CR LF
Fixed Command No. Status Data Checksum
When the measurement status of the unit is “Continue”, and the sensor settings are different from the above
Byte 0 1 2 3 4 5 6 7 8 9 10–16 17 18 19 20
HEX 0×06 0×30 0×30 0×30 0×30 0×30 0×35 0×0D 0×0A
ASCII ACK 0 0 0 0 0 5 ST1 ST2 ST3 Load value × × CR LF
Fixed Command No. Status Data Checksum
When the measurement status of the unit is not “Continue”
Byte 0 1 2 3 4 5 6 7 8 9 17 18 19 20
HEX 0×06 0×30 0×30 0×30 0×30 0×30 0×35 0×0D 0×0A
ASCII ACK 0 0 0 0 0 5 ST1 ST2 ST3 × × CR LF
Fixed Command No. Status Checksum
Status
ST1 (command status)
0: Ready, 1: Busy, 2: Error, 3: Continuous transmission active
ST2 (measurement status)
0: Continue, 1: Wait, 2: Rec, 3: Stop
ST3 (continuous judgment)
0: NO, 1: OK, 2: LL, 3: LO, 4: HI, 5: HH, 6: HL, 7: NG, 8: FULL, 9: OVER
