9. Specifications
Load
Bridge voltage DC, 2.5/5/10V, ±10% (30mA current maximum, can be used with remote sensing)
Signal input range ±3.2mV/V
Equivalent
input/
TEDS
Calibration range 0.1mV/V – 3.2mV/V
Calibration
precision
Within 0.1% F.S. (when using 1m standard TEAC Ø8, 4-core shielded cable with
350Ω impedance, 10V BV and 3.2mV/V setting)
Precision
Linearity Within 0.01% F.S. +1 digit (when input is 3.2mV/V)
Zero drift Within 0.5μV/°C (input conversion value)
Gain drift Within ±0.005% F.S./°C
A/D conversion 24-bit, 5000 times/second, 25000 times/second
Low-pass filter Select 3, 10, 30, 100, 300, 1000Hz(−6dB/oct) or Off
D/A output
Output with same frequency as A/D conversion, isolated output, ±1–±10V output
(set in 1V steps) and about 1/59000 resolution (when set to ±10V), or 4–20mA
current output and about 1/43000 resolution
TEDS function IEEE1451.4 class 2 mix mode interface
Displacement
Pulse
Pulse type A/B phase or A phase, differential square wave (RS-422 conformance)
Maximum input
frequency
2MHz
Maximum count
number
15000000
Power output +5 V ±10%, 500 mA
Voltage
Input ±5.2V
Low-pass filter 10/30/100/300Hz
Power output DC 12V ±10%, 250 mA
Display 4.3" color LCD (480×272)
Indicator value
Display range −32000 to 32000
Decimal point Display position selectable
Times displayed 4 times/second
External input and output
signals
Input
Differential pulse position sensor (A phase, B phase), force backlight lighting, pre-
vent touchscreen operation, force reset, work switching (4-bit), switch zone, clear
results (reset measurement results), enable/disable judgment output, start/stop
measurement, zero balance displacement, digital zero
Isolated from main unit circuits using a photocoupler
Output
Load judgment output (HH, HI, OK, LO, LL), displacement judgment output (HI,
OK, LO), load cell error, measurement complete, trigger output (1, 2)
Open collector output (isolated from main unit circuits using a photocoupler)
RS-232C RXD, TXD
Power supply Ratings: 24V DC ±10%, 13W
Operating temperature range 0°C to 40°C
Storage temperature range −20°C to 60°C
Operating humidity range 85% RH or less (without condensation)
Applicable standards CE marking, FCC (Class A), UL61010-1
External dimensions (W × H × D) Approximately 114mm × 96mm × 140mm (without protrusions)
Weight About 960g
o Specifications and appearance are subject to change without notice.
o Weight and dimensions are approximate.
o Illustrations in this owner’s manual might differ slightly from production models.
