72
6. Communication functions
6-1-2. Command lists
6-1-2-1. Execution
Content Command No. Setting item Note
Digital Zero 0000 10
Clear Digital Zero 0000 11
Switch to indicator value screen 0000 17
Switch to static strain screen 0000 20
Switch to graph screen 0000 21
Start measurement 0000 22
Stop measurement 0000 23
Reset measurement 0000 24
Zero balance displacement 0000 25
Reset software 0000 100 This restarts the system.
Reset to factory settings 0000 101
6-1-2-2. Polling
Content Command No. Setting item
Indicator value polling 0005 None
Status polling 0006 None
Measurement result polling 0007 None
Peak bottom value polling 0008
0: None, 1: Reset peak, 2: Reset bottom, 3: Reset both
Read hold value 0010 None
6-1-2-3. Waveform and graph
Content Command No. Setting item
Acquire measurement waveform
Load measurement waveform sample number 0100 See page84
Load measurement waveform 0101 See page85
6-1-2-4. Settings
Content Command No. Setting item Note
Locking
Lock calibration values
(CALIBRATION LOCK)
5201 0: Unlock, 1: Lock
Lock work (WORK LOCK) 5202 0: Unlock, 1: Lock
Lock all (ALL LOCK) 5203 0: Unlock, 1: Lock
Lock touchscreen 5204 0: Unlock, 1: Lock
Unlock by turning power off
and on
Backlight setting (LCD BRIGHTNESS) 5301 0 to 3
Backlight time 5302 0 to 255
Language 5303
0: Japanese, 1: English, 2: Chinese, 3:
Korean
Currently, Chinese and
Korean produce errors
Internal memory
Save results (SAVING) 5400 0: NO, 1: AUTO SAVE, 2: SAVE ON ERROR
Overwrite (OVERWRITING) 5401 0: Forbid, 1: Allow
Delete all 5402 100: Execute
OK counter 5410 100: Reset
NG counter 5411 100: Reset
