7. SYSTEM
7-2-5. WORK
Item Setting Format Default value Setting range/options
WORK NUMBER Selection 1 1–16
WORK SWITCHING Selection MANUALLY EXT. INPUT, MANUALLY
COPY WORK Selection ALL ALL, 1, 2, 3, 4
MEASURE. START.
COND. Selection EXT. SIGNAL EXT. SIGNAL, EXT. & LOAD*, EXT. & DISP*
LEVEL Input 50.00
MEASURE. STOP.
COND. Selection EXT. SIGNAL
EXT. SIGNAL, EXT. | LOAD*, EXT. | DISP.*,
EXT. | TIME*
LEVEL Input 100.00
CONTINUOUS JUDGMENT
LO Input 10.00
HI Input 100.00
LL Input −30.00
HH Input 200.00
HHLL Selection HH/LL OFF HH/LL ON, HH/LL OFF
BAND JUDGMENT
SELECT REF. WAVE Selection WAVE SAMPLING WAVE SAMPLING, WAVE LOADING
WAVEFORM COMP. Selection DISABLE DISABLE, ENABLE
*An & shows an AND condition and a | shows an OR condition.
ZONE JUDGMENT
Item Setting Format Default value Setting range/options
ZONE SWITCHING Selection PRESET EXT. INPUT, PRESET
INDICATOR VALUE Selection INPUT VAL.
INPUT VAL., ZONE1, ZONE2, ZONE3,
ZONE4, ZONE5
Zone number Selection 1 1–5
ZONE n Selection DISABLE ENABLE, DISABLE
JUDGE. METHOD Selection CONSTANT
CONSTANT, SAMPLE, PEAK, BOTTOM,
P-P, AVERAGE, MAX/MIN, INFLECTION
ZONE RANGE
START Input 0.000
END Input 2.240
LOAD HIGH (HI)/LOW (LO)
HIGH (HI) Input 100.00
LOW (LO) Input 10.00
DISPLACEMENT (HI)/(LO)
HIGH (HI) Input 10000
LOW (LO) Input 0
