7-2-4-2. DISPLACE. SENSOR
Item Setting Format Default value Setting range/options
UNIT SHOWN Selection mm μm, mm, cm, m, rad, deg, ---
CALIBRATION LOCK Selection OFF ON, OFF
INPUT MODE Selection PULSE PULSE, VOLTAGE
PULSE INPUT
Item Setting Format Default value Setting range/options
EQUIVALENT CALIB.
OUTPUT PHASE (AB, A) Selection AB-phase AB-phase, A-phase
ZERO BALANCING Measurement EXECUTE
COUNT NUMBER Input 10000 1–15000000
DISPLAY VALUE Input 100.00 00001–99999
ZERO POSITION Input 0
MOVING AVG. NUM. Input 0 0, 2–2048
ACTUAL LOAD CALIB.
OUTPUT PHASE (AB, A) Selection AB-phase AB-phase, A-phase
ZERO BALANCING Measurement EXECUTE
DISPLAY VALUE Measurement 100.00 00001–99999
ZERO POSITION Input 0
MOVING AVG. NUM. Input 0 0, 2–2048
VOLTAGE INPUT
Item Setting Format Default value Setting range/options
EQUIVALENT CALIB.
ZERO BALANCING Measurement EXECUTE
RATED OUTPUT Input 5.000 0.100–5.200V
DISPLAY VALUE Input 100.00 00001–99999
ZERO POSITION Input 0
LOW-PASS FILTER Selection 300Hz 10Hz, 30Hz, 100Hz, 300Hz
MOVING AVG. NUM. Selection 16 0, 2–2048
ACTUAL LOAD CALIB.
ZERO BALANCING Measurement EXECUTE
DISPLAY VALUE Input 100.00 00001–99999
ZERO POSITION Input 0
LOW-PASS FILTER Selection 300Hz 10Hz, 30Hz, 100Hz, 300Hz
MOVING AVG. NUM. Input 16 0, 2–2048
