Teac TD-9000T User Manual

91
7-2-4-1. LOAD CELL
Item Setting Format Default value Setting range/options
EQUIVALENT CALIB.
BRIDGE VOLTAGE Selection 2.5V 2.5V, 5V, 10V
RATED OUTPUT Input 3.000mV/V 0.100–3.200mV/V
RATED CAPACITY Input 100.00 00001–99999
ZERO BALANCING Measurement CALIBRATION
UNIT SHOWN Selection N
dN, N, kN, g, kg, ton, mN·m, N·m, kN·m,
Pa, kPa, MPa, mBar, Bar, m/s2, Gal,
mm, ---
LINEARIZE CALIB.
Measurement
CALIBRATION
ACTUAL LOAD CALIB.
BRIDGE VOLTAGE Selection 2.5V 2.5V, 5V, 10V
ZERO BALANCING Measurement CALIBRATION
RATED CAPACITY Measurement 100.00 00001–99999
UNIT SHOWN Selection N
dN, N, kN, g, kg, ton, mN·m, N·m, kN·m,
Pa, kPa, MPa, mBar, Bar, m/s2, Gal,
mm, ---
LINEARIZE CALIB. Measurement CALIBRATION
TEDS CALIB.
TEDS CALIB. Measurement CALIBRATION
ZERO BALANCING Measurement CALIBRATION
UNIT SHOWN Selection N
dN, N, kN, g, kg, ton, mN·m, N·m, kN·m,
Pa, kPa, MPa, mBar, Bar, m/s2, Gal,
mm, ---
TEDS DATA DISPLAY Selection EXECUTE
REWRITE TEDS DATA Selection EXECUTE
RESTORE TEDS DATA Selection EXECUTE
EQUIVALENT CALIB.
Item Setting Format Default value Setting range/options
LINEARIZE CALIB.
LINEARIZE CALIB. Selection OFF ON, OFF
Selection point Selection DISABLE ENABLE, DISABLE
DELETE POINT Execution Selection
OUTPUT VAL. Input 0 – rated output value
LOAD VAL. Input 0–99999
ACTUAL LOAD CALIB.
Item Setting Format Default value Setting range/options
LINEARIZE CALIB.
LINEARIZE CALIB. Selection OFF ON, OFF
Selection point Selection DISABLE ENABLE, DISABLE
DELETE POINT Execution Selection
LOAD INPUT VAL. Measurement Current load value
LOAD OUTPUT VAL. Input 0–99999
7. Setting lists
