7-2-4. SENSOR
Item Setting Format Default value Setting range/options
SENSOR MEMORY Selection 1 1–4
SAMPLING RATE Selection 25kHz 5kHz, 25kHz
Y AXIS Selection LOAD LOAD, LOAD & DISPLACE.
X AXIS Selection TIME TIME, DISPLACE.
X AXIS FULL SCALE Selection Time: 2.0s
Time: 80ms*,170ms*,400ms, 800ms,
2.0s, 4.0s, 10.0s, 30.0s, 60.0s, 90.0s
Displacement: 2000, 4000, 6000, 8000,
10000, 15000, 20000, 30000
D/A OUTPUT SETTING Selection VOLTAGE VOLTAGE, CURRENT
D/A MAX. VOLTAGE Input 10V 0–10V
D/A ZERO Input 0.00 ±99999
D/A FULL SCALE Input 100.00 ±99999
LOAD CELL
UNIT SHOWN Selection N
dN, N, kN, g, kg, ton, mN·m, N·m, kN·m,
Pa, kPa, MPa, mBar, Bar, m/s2, Gal,
mm, ---
MAX. DISP. VALUE Input 110.00 00000–32000
MOVING AVG. NUM. Input 16 0, 2–2048
LOW-PASS FILTER Selection 100Hz
3Hz, 10Hz, 30Hz, 100Hz, 300Hz,
1000Hz, Off
CALIBRATION LOCK Selection OFF ON, OFF
SENSOR INPUT LOGIC Selection STANDARD STANDARD, REVERSED
REMOTE SENSING Selection
UNUSED
(4wire)
USED (6wire), UNUSED (4wire)
AUTO DIGITAL FILTER Selection ON ON, OFF
DIGITAL OFFSET Input 0.00 00000–99999
D/Z LIMIT SETTING Input 999.99 00000–99999
*80ms and 170ms cannot be selected when the sampling frequency is set to 5 kHz.
