84
6-1-4-6. Load number of measurement waveform samples (0100)
If the measurement status of the unit is “Stop”, the most recent measurement result will be returned. If the measurement status of the
unit is anything else, an error (NAK) will be returned.
Command
HEX 0×23 0×30 0×30 0×30 0×31 0×30 0×30 0×32 0×31 0×0D 0×0A
ASCII # 0 0 0 1 0 0 2 1 CR LF
Fixed Command No. Checksum
Response
When the measurement status of the unit is “Stop”
Byte 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
HEX 0×06 0×30 0×30 0×30 0×31 0×30 0×30 0×0D 0×0A
ASCII ACK 0 0 0 1 0 0 LOAD TIME DISP
BAND NUM
× × CR LF
Fixed Command No. Status Data Checksum
When the measurement status of the unit is not “Stop”
Byte 0 1 2
HEX 0×15 0×0D 0×0A
ASCII NAK CR LF
Status
LOAD, TIME, DISP, BAND
0: Disabled, 1: Enabled
Data
NUM
Number of samples
6. Communication functions
