Teac TD-9000T User Manual

83
6-1-4-5. Read hold value (0010)
If the measurement status of the unit is “Stop”, the status and hold value will be returned. If the measurement status of the unit is any-
thing else, an error (NAK) will be returned.
Command
HEX 0×23 0×30 0×30 0×30 0×30 0×31 0×30 0×30 0×30 0×0D 0×0A
ASCII # 0 0 0 0 1 0 START STOP × × CR LF
Fixed Command No. Data Checksum
Data
START
Measurement result that starts transmission
0: Band judgment, 1–5: Zone number
STOP
Measurement result that ends transmission
0: Band judgment, 1–5: Zone number
NOTE
o The transmission order is Band judgment, Zone1 judgment, Zone2 judgment, Zone3 judgment, Zone4 judgment, Zone5
judgment.
o The judgments will be separated by commas.
Responses
Example of measurement result response when the measurement status of the unit is “Stop” (START: 0, STOP: 1)
Byte 0 1 2 3 4 5 6 7 8–26 27 28–46 47 48 49 50
HEX 0×06 0×30 0×30 0×30 0×30 0×31 0×30 0×2c 0×2c 0×0D 0×0A
ASCII ACK 0 0 0 0 1 0 ,
Load,
displacement
,
Load,
displacement
× × CR LF
Fixed Command No. Band judgment Zone 1 judgment Checksum
Band/zone judgment format
Byte +0 +1 +2 +3 +4 +5 +6 +7 +8 +9 +10 +11 +12 +13 +14 +15 +16 +17 +18
HEX 0×2c 0×2c 0×2c
ASCII J_L , ± × × × × × × , J_D , ± × × × × × ×
Load value (including decimal places) Load value (including decimal places)
J_L (load judgment), J_D (displacement judgment)
0: NO, 1: OK, 2: LL, 3: LO, 4: HI, 5: HH, 6: HL, 7: NG, 8: FULL, 9: OVER
When the measurement status of the unit is not “Stop”
Byte 0 1 2
HEX 0×15 0×0D 0×0A
ASCII NAK CR LF
6. Communication functions
