82
6-1-4-4. Peak & bottom polling (0008)
If the measurement status of the unit is “Continue”, the status, peak value and bottom value will be returned. If the measurement sta-
tus of the unit is anything else, only the status will be returned.
NOTE
This command returns the peak and bottom values of continuous judgment.
Command
HEX 0×23 0×30 0×30 0×30 0×30 0×30 0×38 0×32 0×36 0×0D 0×0A
ASCII # 0 0 0 0 0 8 2 8 CR LF
Fixed Command No. Checksum
Responses
When the measurement status of the unit is “Continue”
Byte 0 1 2 3 4 5 6 7 8 9 10–16 17 18–24 17 18 19 20
HEX 0×06 0×30 0×30 0×30 0×30 0×30 0×38 0×2c 0×0D 0×0A
ASCII ACK 0 0 0 0 0 8
CHECK
ST1 ST2 PEAK , BOTTOM × × CR LF
Fixed Command No. Status Data Checksum
When the measurement status of the unit is not “Continue”
Byte 0 1 2 3 4 5 6 7 8 9 10 11 12 13
HEX 0×06 0×30 0×30 0×30 0×30 0×30 0×38 0×0D 0×0A
ASCII ACK 0 0 0 0 0 8
CHECK
ST1 ST2 × × CR LF
Fixed Command No. Status
Checksum
Status
CHECK (measurement complete condition)
0: No, 1: Check
o This becomes 1 when measurement completes and becomes 0 after reading once.
ST1 (command status)
0: Ready, 1: Busy, 2: Error, 3: continuous transmission active, 4: sending results automatically
ST2 (measurement status)
0: Continue, 1: Wait, 2: Rec, 3: Stop
Data
PEAK (peak value)
10: ± sign, 11–16: Load value (including decimal places)
Byte 10 11 12 13 14 15 16
ASCII ± × × × × × ×
BOTTOM (bottom value)
18: ± sign, 19–24: Load value (including decimal places)
Byte 18 19 20 21 22 23 24
ASCII ± × × × × × ×
6. Communication functions
