73
6-1-2-5. System
Content Command No. Setting item
Device number 5500 0–9999
Beep 5501 0: OFF, 1: KEY, 2: KEY + JUDGE
External measurement signal mode (EXT. START/STOP) 5502 0: Edge, 1: Level
Date & time setting
Format 5503 0: YYYY-MM-DD, 1: DD-MM-YYYY, 2: MM-DD-YYYY
Date (year, month and day) 5504 YYMMDD
Time 5505 HHMMSS
Trigger output 1
Output item 5510 0: None, 1: Load, 2: Displacement, 3: OK count, 4: NG count
Load output threshold (HI) 5511 ±99999
Load output threshold (LO) 5512 ±99999
Displacement output threshold
(HI)
5513 ±99999
Displacement output threshold
(LO)
5514 ±99999
OK count threshold 5515 0–99999
NG count threshold 5516 0–99999
Trigger output 2
Output item 5520 0: None, 1: Load, 2: Displacement, 3: OK count, 4: NG count
Load output threshold (HI) 5521 ±99999
Load output threshold (LO) 5522 ±99999
Displacement output threshold
(HI)
5523 ±99999
Displacement output threshold
(LO)
5524 ±99999
OK count threshold 5525 0–99999
NG count threshold 5526 0–99999
Version display (F/W VERSION) 5530 None
6-1-2-5-1. SD card
Content Command No. Setting item Note
Automatic saving (AUTO SAVE) 5600 0: NO, 1: AUTO SAVE, 2: SAVE ON ERROR
Format 5601 1: Execute
6. Communication functions
