Teac TD-9000T User Manual

69
5. System settings
Recording data example
[Information]
Device ID,0 d device number
Date,2020/03/31 d measurement date
Time,17:47:39 d measurement time
Sensor No.,4 d sensor number
Work No.,7 d work number
Sampling Freq.,25kHz d sampling frequency
X Axis,Time(sec) d X axis
Y Axis,Load(N) d Y axis
X Fullscale,4.00(sec) d X axis full-scale
[Result]
Total Judge.,OK d overall judgment
Total Load Judge.,OK d load judgment
Total Disp Judge.,-- d displacement judgment
,BAND,ZONE1,ZONE2,ZONE3,ZONE4,ZONE5, d judgments
Hold Method,,Constant,Peak,Bottom,Constant,Inflect, d judgment methods
Load Judge.,OK,OK,OK,OK,OK,OK, d load judgments
Disp Judge.,,--,--,--,--,--, d displacement judgments
Hold Point,1.486(sec),0.899(sec),1.296(sec),1.997(sec),3.239(sec),3.845(sec), d hold points
Hold Data,25.96(N),27.96(N),28.95(N),17.22(N),31.67(N),19.18(N), d hold values
Zone Start,0.781(sec),0.000(sec),1.080(sec),1.980(sec),2.520(sec),3.060(sec), d zone starting points
Zone End,1.487(sec),0.900(sec),1.800(sec),2.700(sec),3.240(sec),4.032(sec), d zone ending points
Zone Hi Limit,,50.00(N),45.00(N),50.00(N),45.00(N),40.00(N), d load high limit values
Zone Lo Limit,,0.00(N),10.00(N),10.00(N),10.00(N),5.00(N), d load low limit values
Zone Disp. Hi,, d displacement high limit
Zone Disp. Lo,, d displacement low limit
[Wave Data]
[X] Time(sec),[Y] Load(N),Bandwave(Hi),Bandwave(Lo) d data header
0.000,22.62,, d sampling data follows this
0.001,22.62,,
±
0.779,27.18,,
0.781,27.20,18.47,35.47
0.783,27.23,18.47,35.47
0.784,27.25,18.48,35.48
0.786,27.27,18.49,35.49
±
4.028,40.57,,
4.030,40.69,,
Header section
  
Measurement data Judgment results

Data section
Judgment method
Constant (constant judgment)
Sample
Peak
Bottom
P-P (peak-to-peak)
Average
Maximum
Minimum
Inflect (inflection point)
