86
6-1-4-8. TEDS command format
Command numbers 6001–6006 are transmitted in this format.
Data is fixed to 8 characters. If the data lacks 8 characters, each opening will be filled with a "0".
Command
Example of TEDS maximum rated capacity (6002)
HEX 0×23 0×30 0×31 0×36 0×30 0×30 0×32 0×32 0×39 0×0D 0×0A
ASCII # 0 1 6 0 0 2 2 9 CR LF
ID number Command No. Checksum
Response
Example of TEDS maximum rated capacity (6002)
HEX 0×06 0×30 0×31 0×36 0×30 0×30 0×32 0×32 0×30 0×30 0×32 0×30 0×30 0×30 0×30 0×41 0×44 0×0D 0×0A
ASCII ACK 0 1 6 0 0 2 2 0 0 2 0 0 0 0 A D CR LF
ID number Command No. 8 data characters Checksum
Data
The decimal point position is 2, so the rated capacity is 200.00.
Maximum rated capacity (6002), maximum rated output (6003) and sensor impedance (6004) data formats
Byte +0 +1 +2 +3 +4 +5 +6 +7
HEX
ASCII POS × × × × × × ×
Data (no decimal point)
POS (decimal point position)
0: none, 1: 0.0, 2: 0.00 3: 0.000, 4: 0.0000
6. Communication functions
