TECALEMIT HDA eco - WLAN Connection

26 44 1670 001-GB-I
HDA eco
3.1.5.5 WLAN connection
The link via the WLAN interface to an existing WLAN network enables communication
to a PC. The PC must be in the same network. For details concerning the connection
and the necessary settings, see chapter 5.3.4.3.10.
Connection diagram
HDA eco
PC
HD
Manager
PCB HDA eco
Local area network
WLAN socket
modem
WLAN access point
WLAN antenna
