TECALEMIT HDA eco - Annex A. Menu Structure Management Operation

80 44 1670 001-GB-I
HDA eco
Annex A. Menu Structure Management Operation
Main Menu
Refuelling Data
Total Data
Ident Codes
System
Fuel Tank
Menu Refuellings
Show Refuellings
Print Refuellings
Reset Refuellings
No. of Refuellings
USB-Report Refuellings
Menu Total Data
Totals Driver
Totals Vehicle
Menu Ident Codes
Driver
Vehicle
Master
USB report
Web Update
Menu System
Refuelling Options
Dispensing Point
Extended
Transponder
-
ID
Menu Refuelling Options
Identification
Mileage y/n
Previous Mileage y/n
Order No y/n
Nozzle Switch y/n
Refuelling Limit
Max. Refuelling time
Time Out Refuelling
Receipt
Menu Dispensing Point
Pulses / Liter
Post Decimals
Automat Lock
Device Address
Max. Zero
Dispensings
Menü Extended
Date / Time (RTC)
Contrast LCD
Language
Language from USB
Initialisation
Info Configuration
Activation
Communication Pin
USB Pin
Interface
Menu Tank Parameters
Form
Max. Volume
Height
Density Medium
Sensor Type
Offset Sensor
Min. Volume
Zero point adjust
Menu items are selected
with the ‘’ and ‘’ keys
and confirmed by pressing
the ‘ENTER’ key.
Sub-menus or menu items
can be quitted by pressing
the ‘EXIT’ key.
Pressing the ‘EXIT’ key in
the main menu switches to
the Refuelling mode.
Menu items in italics are
optional / not available in
all versions.
Menu RTC
Date / Time
Clock Correktion
Daylight Saving Time
Totals Driver
Display Totals
SummReset Totals
USB Report Totals
Totals Vehicle
Display Totals
SummReset Totals
USB Report Totals
Driver
Code
PIN
Locked
Vehicle
Code
PIN
Refuelling Limit
Max. Refuelling time
Request miles / hours
Range miles / hours
Status miles / hours
Quota quantity
Quota time frame
Lock ID
Master
Code
PIN
Menu Fuel Tank
Stock Control
Tank Parameters
Tank Level
Menu Interface
Submenu structure
according to
version, see next
page
