44 1670 001-GB-I

HDA eco

Annex B. Functional Principle

hdmanager.net

Schematic for one Customer with three HDA eco

Internet

HTE Web Server

1234567890

Unique Customer ID

01823481

01823482

01823483

Unique Ident Number for each HDA

HDA eco equipped with M2M SIM cards

- Assignment HDA to customer

- Control data stream

CMR

HD Manager 8

LAN
