TECALEMIT HDA eco - Zero Point Compensation Sensor; Tank Level (Level Probe Option)

72 44 1670 001-GB-I
HDA eco
5.3.5.2.8 Zero Point Compensation Sensor
Attention:
The sensor must be outside the liquid for the zero point compensation.
Display (e.g.):
The presently measured probe current is displayed after pressing the ‘
ENTER
’ button.
The value should be within the range 4 mA +/- 0.2 mA.
Display (e.g.):
Pressing the ‘
ENTER
’ button twice executes the zero point compensation for the
probe, while the ‘
EXIT
’ button aborts the compensation.
5.3.5.3 Tank Level (Level Probe Option)
The filling quantity in percent, the measured filling level and the filling quantity in li-
tres are displayed.
Display (e.g.):
Tank parameters
◄►Zero adjust?
Zero compensation
Current: 4.05 mA
Tank 20%
510mm 6800L
