44 1670 001-GB-I
HDA eco
47
5.3.4.1.1 Identification
Display (e.g.):
The query of the driver and vehicle ID is optional.
You can choose between ‘No’, ‘Driver’, ‘Vehicle’ and ‘Both’.
If Identification: ‘no’ has been selected and the order and mileage queries have also
been deactivated, refuelling will begin as soon as the ENTER button is pressed or
the nozzle is drawn when a nozzle switch is installed!
5.3.4.1.2 Odometer y/n
Display (e.g.):
Entering the tachometer value before each dispensation is optional. You can choose
between "Request", "Do not request", "Forced mode 1" and "Forced mode 2".
Mode Function
1 Updating of mileage by querying database.
Dispensation will still be possible even if the database connection fails.
2 Updating of mileage by querying database.
Dispensation will
not
be possible even if the database connection fails.
The querying of the current mileage can only be done via a LAN or WiFi interface
and the HD Manager program, but not via a connection to hdmanager.net or myte-
calemit Cloud.
Selecting "Forced mode" means that an input with a verification of the value will be
obligatory. The value entered must be equal to or larger than the last value entered,
but the difference between it and the last value entered must be smaller than the
window
defined for the vehicle (see chapter 5.3.3.1.5). If the consumption of the cor-
responding vehicle is calculated according to hours of operation, the same will apply
analogously for the input of the hours of operation.
5.3.4.1.3 Previous Odometer y/n
Display (e.g.):
In order to simplify the odometer entry, the odometer reading (km / mls) from the last
refuelling event (if available) can be displayed and edited. You can choose between
‘yes’ and ‘no’. In case a consumption calculation according to operating hours takes
place for the vehicle in question, the same applies in turn for the display of the oper-
ating hours.
Identification
◄► Vehicle
Odometer
◄►do not inquire
Prev. Odometer
◄►yes
To Next Page
