64 44 1670 001-GB-I
HDA eco
5.3.4.3.11.18 Port (WLAN)
Display (e.g.):
This is where the address should be entered of the port where communication is sup-
posed to take place.
For communication with the HD Manager program, it is recommended that the
standard port 54937 be used. The setting must be identical with the corre-
sponding setting in the HD manager PC program. This also applies if several
HDA ecos communicate with a computer program.
For communication with mytecalemit Cloud or www.hdmanager.net,
Port = 80 must be configured.
If, for example, two HDA eco have to communicate in an existing network, however
each with a different computer, two different ports have to be selected for the re-
spective HDA eco / PC pairs using the HD Manager 8 computer program.
5.3.4.3.11.19 MAC Address (WLAN)
Display (e.g.):
This is where the MAC address of the socket modem can be viewed.
5.3.4.3.12 Menu Interface for CMR socket modem option
Display (e.g.):
This menu is only available if a CMR socket modem is present (option). This is where it
is possible to enter the necessary parameters for operating the CMR socket modem. If
necessary, the support of the selected Internet Service Provider (ISP) should be con-
sulted for the correct settings. Select the menu points using the ‘▲ and ‚▼‘ buttons
and confirm with 'ENTER', abort with 'EXIT'.
CMR is short for cellular mobile radio. Various wireless modems can be installed in
the CMR socket modem, e.g. GPRS or UMTS.
5.3.4.3.12.1 Ident No. (CMR)
Display (e.g.):
This is where you can see the identification number (device serial no.) for clear identi-
fication of the HDA eco in the network (unchangeable). Via the identification number
the HDA eco can be identified in a pool of several devices assigned to one customer.
Leave the menu point with 'EXIT'.
Port
MAC Address:
Menu Interface
Ident. No.:
