52 44 1670 001-GB-I
HDA eco
5.3.4.3.2 Contrast LCD
Display (e.g.):
The contrast can be decreased or increased using the ‘⊳’ and ‘►’ buttons.
The setting range extends from 0 (low contrast) to 63 (high contrast). Changing the
default value should only be necessary under extreme operating conditions (very
low/very high temperatures).
In case the incorrect contrast has been saved inadvertently (display unreadable):
Switch off the device and switch on again keeping the ‘EXIT’ button pressed (standard
contrast will be selected). Subsequently adjust the contrast as described.
5.3.4.3.3 Language
Display (e.g.):
Various languages for the driver menus are to be selected using the ‘⊳’ and ‘’ but-
tons. One of the languages (‘language USB’) can be loaded and selected as defined by
the driver (see section 0).
5.3.4.3.4 Language from USB flash drive
Display (e.g.):
It is possible to load an additional language for the user guidance from a USB flash
drive. The prerequisite for this is that a USB flash drive containing a suitable language
file ‘LANGUAGE.CSV’ is inserted in the USB port provided for it on the automatic dis-
penser. For further information see 0.
Contrast LCD
Language
Reading file
