70 44 1670 001-GB-I
HDA eco
5.3.5.1 Stock Control
Stock control of the tank contents including blocking of the dispensing point in case of
empty tank can be switched on or off. This applies both to control by means of a low
medium contact (e.g. float switch) and to the control and display of the tank contents
by means of a level probe (optional).
Display (e.g.):
You can choose between ‘yes’ and ‘no’. When the setting is ‘no’, the ‘’ key has no
function. The tank volume is not displayed.
Note:
In the case of use of the low medium contact, the automatic dispenser is disabled
when the contact switches from the closed to the open state. The level at which disa-
blement takes place when a level probe (optional) is used depends on the setting of
the disable volume (see section5.3.5.2.7).
5.3.5.2 Tank Parameter Menu (Option Level Probe)
In the case of use of a level probe, it is necessary to parameterise the probe and the
associated tank as accurately as possible in order to obtain exact level values.
You can switch between the different tank parameters using the ‘◄’ or ‘►’ buttons.
Press the ‘
ENTER
’ button to change the parameter and ‘
EXIT
’ to complete the entry.
Instructions for the installation of the level probe in the tank can be found in section
3.1.3
5.3.5.2.1 Form / Tank Shape
The form of the employed tank can be set here. If there is no tank, then accordingly
no tank is set (shape ‘---‘).
Display (e.g.):
Change the tank form using the buttons ‘◄’ and ‘’. There is a choice of the tank
forms Cube, Cylinder vertical (‘Cyl V’), Cylinder horizontal (‘Cyl H’), ‘Ball’
or no tank (---).
5.3.5.2.2 Max. Volume / Maximum Tank Volume
The maximum tank volume can be entered here. It corresponds to a completely filled
tank.
Display (e.g.):
A value of between 0 and 99999 litres can be entered.
Tank parameters
Stock control
Tank parameters
