60 44 1670 001-GB-I
HDA eco
5.3.4.3.11.3 Read Configuration (WLAN)
Display (e.g.):
Optionally, the network configuration of the HDA eco can be entered directly on the
device or created conveniently with the aid of the HD Manager 8 computer program
and stored on a USB pen drive in the folder that belongs to the device (HD Manager 8:
Settings Settings Miscellaneous HDA – (W)LAN / CMR). In this menu, the previ-
ously stored configuration is imported from the USB pen drive into the HDA eco. Fol-
lowing this, you can leave the 'Interface' menu. As a general rule, further settings are
not needed.
5.3.4.3.11.4 Signal (WLAN)
Display (e.g.):
This is where the signal level and the quality of the connection to the existing wire-
less network can be examined. Higher values indicate a better connection. A signal
level and quality above 30% indicates a stable connection.
This menu point is helpful in order to optimize measures for improving reception
quality (e.g. external aerials, repeaters etc.).
5.3.4.3.11.5 Restart Time (WLAN)
Display (e.g.):
This menu item is only available for operation with mytecalemit Cloud.
This is the place where a time can be selected, to which the WLAN Socketmodem is
restarted once a day and at the WLAN network registers itself again. A periodic re-
start can create remedy with sporadic connecting difficulties. In stable WLAN net-
works factory setting „off“ can be used.
5.3.4.3.11.6 Send delay (WLAN)
Display (e.g.):
This menu item is only available for operation with mytecalemit Cloud.
This is where users can define the time delay after which a completed dispensation is
transmitted to the web server. A higher value can e.g. enable the operator to perform
several refueling procedures in succession before subsequently transferring them in
batch to save time. A value between 0 seconds (transmission directly upon comple-
tion of refueling procedure) and 255 seconds can be entered. The factory default is
20 seconds.
Level : 67%
Restart Time
Insert
Send delay
To Next Page
