SYNCHRO EXCITE Class & Trend: Service & maintenance manual - rev. 2.0
Page 2.13
CU164: Audio/Video signal cable
(Digital TV board – AUX input board)
Digital TV board
J10
Signal Colour
AUX input board
1 GND video Black 1
2 Signal video Black 2
3 GND audio L Black 3
4 Signal audio L Black 4
5 Signal audio R Black 5
6 GND audio R Black 6
n.c. Black 7
CU166: CSafe – iPod – Video signals cable
(Digital TV board – AUX input board)
Digital TV board
J9
Signal Colour
AUX input board
1 Power supply +8 Vdc Black 1
2 Power supply +8 Vdc Black 2
3 Power supply +8 Vdc Black 3
6 RX – TX Black 7
7 TX – RX Black 6
8 CTS Black 8
9 Power supply +5 Vdc Black 9
10 Power supply +5 Vdc Black 10
11 GND DTV board sensing Black 11
12 GND “Play” sensing Black 12
13 GND Black 13
14 GND Black 14
15 n.c. Black -
CU167: iPod signals cable
(AUX input board – Docking Station)
AUX input cable
Signal Colour
Docking Station
1 +V bus USB Black 14
2 GND bus USB Black 13
3 TX - RX Black 11
4 RX – TX Black 12
5 CTS Black 10
6 +5Vdc Black 9
7 GND Black 8
8 GND Black 7
9 GND video signal Black 6
10 Video signal Black 5
11 GND Lef audio signal Black 4
12 Left audio signal Black 3
13 Right audio signal Black 2
14 GND Right audio signal Black 1
