6.14.2. HAND SENSOR
The machine displays this error if the HS interface board is not working, or if it is not supplied by
the display board.
For an easier and quicker diagnosis of the problem, we recommend to use the functions of Test
Box Excite.
THERE IS NO HR
SIGNAL
Are the sensors correctly
connected to the connectors
board?
Reinstate the connection
2
YES
NO
Is the supply voltage correct at
the input to the HS interface
board?
Replace the HS interface
board
3
YES
NO
Is the connectors board
correctly connected to the HS
interface board?
Reinstate the connection
YES
NO
Is the supply voltage correct on
the patch connector 6?
Replace the
ELT-31 cable
4
YES
NO
Check the earth connection
of the machine
1
A
Continued on the following page.
