SYNCHRO EXCITE Class & Trend: Service & maintenance manual - rev. 2.0
Page 4.1
4. ACCESSORIES
4.1. CARDIO THEATER CONNECTION
The machine can be connected to the CardioTheater by means of the RJ45 connector on the CSafe
board. The CardioTheater unit must be provided with a power cable having the following pin-out:
RJ45 Connector Signal
5 +5 Vdc
7 Ground
WARNING: for the numbering of the pins, on RJ45 connector, please refer to the diagram
below:
