SYNCHRO EXCITE Class & Trend: Service & maintenance manual - rev. 2.0
Page 6.19
Replace the CU160 cable.
Working?
Replace the Digital TV
board
and / or
the CPU board
NO
CU160 cable def ective
Check the conditions of
antenna cable.
It is CU-198 ok?
Replace the CU-198
cable.
NO
A
Is the TV standard correctly
conf igured?
Configure the
"TV standard"
parameter
NO
2
YES
3
Check the Antenna
signal.
4
YES
YES
YES
YES
Follow the procedure step by step to correctly diagnose the problem. Take particular care with the
checks highlighted by circled numbers, which are described in detail below:
