Troubles: Information about the current Troubles in the system.
• LED Keypad;
[Fx] [6] → [Master Code] → [Press 6]
Indicates the Troubles on the Keypad one by one. You can find the Trouble codes below.
• LCD Keypad;
[Fx] [6] → [Master Code] → [6-Troubles]→ [√ OK]
Indicates the Troubles on the Keypad one by one.
LED Trouble codes and related LED information are indicated on the keypad as follows;
0-1 Power Failure 1-0 Keypad Connection Fault
0-2 Low Battery 1-1 GSM/GPRS Module Fault
0-3 Wrong Time and Date 1-2 PSTN Module Fault
0-4 No PSTN Line 1-3 Ethernet Modul Fault
0-5 Zone Fault 1-4 SIM Card Fault
0-6 Battery Fault 1-5 GSM Communication Fault
0-7 Tamper 1-6 GPRS Communication Fault
PS 1: LED Keypad displays fault messages by illuminating zone numbers in sequence. For example, if
the PSTN Module Error occurred in the system, when entering the Reports - Troubles section, the
LED Keypad will display as follows;
[1] [2] will light up and then all LEDs will light up.
PS 2: If more than one fault is present, the LED Keypad displays all faults in sequence. All LEDs flash
simultaneously between each fault indication. For example, if both PSTN Module Error and SIM Card
Error are present in the system, when you enter the Reports - Troubles section, the LED Keypad will
display as follows;
[1] [2] will light up and then all LEDs will light up. Then [1] [4] will light up and then all LEDs
will light up.
GSM Signal: GSM signal level can be displayed on panels with GSM sim card. GSM signal shown as
percent “%” . Access to GSM signal level information is as follows and the value shown here can be
interpreted according to the following information.
• LED Keypad;
[Fx] [6] → [Master Code] → [Press 7]
Signal Level according to LED indicates;
1: Signal Level Between %1 - %12,5
1-2: Signal Level Between %12,5- %25
1-2-3: Signal Level Between %25 - %37,5
1-2-3-4: Signal Level Between %37,5 - %50
1-2-3-4-5: Signal Level Between %50 - %62,5
1-2-3-4-5-6: Signal Level Between %62,5 - %75
1-2-3-4-5-6-7: Signal Level Between %75 - %87,5
1-2-3-4-5-6-7-8: Signal Level Between %87,5 - %100
