Teknim VAP404 - Page 19

TD-1/07-008
19 / 83
04 01
04 02
Account No
Central M. Station-1(CMS-1)
Central M. Station-2(CMS-2)
AAAA = 4 digit number
0000
0000
40 IP
05 01
05 02
05 03
05 04
CMS Phone numbers
CMS-1
CMS-2
Secondary number of CMS-1
Secondary number of CMS-2
TTTTTTTTTTTTTTT max. 15 digit phone number
(*) CMS dialing is enabled( 1. option in 50 01 )
automatically when phone number is entered.
---
---
41 IP
06 01
06 02
06 03
06 04
06 05
06 06
User Phone Numbers
User Phone-1
User Phone-2
User Phone-3
User Phone-4
User Phone-5
User Phone-6
TTTTTTTTTTTTTTT max. 15 digit phone number
(*) User Phone Dialer is enabled( 2. option in 50 01 )
automatically when phone number is entered.
---
---
---
---
---
41 IP, MP
07 01
07 02
07 03
07 04
07 05
07 06
07 07
07 08
User Codes
User Code-1
User Code-2
User Code-3
User Code-4
User Code-5
Guest Code
Duress Code
PC Connection Code
xxxx = 4 digit code;
If “0000” is entered, that user becomes disabled.
0000
0000
0000
0000
0000
0000
0000
7777
42 MP
10 01
Panel Settings
(ON/OFF)
1. option= Smart Partition Technology Enable/Disable
2. option= Quick Arm Enable/Disable
3. option= Auto Siren Test Enable/Disable
4. option= Arm/Disarm from Foreign Keypad Enable/Disable
5. option= Extendable Exit Delay Enable/Disable
6. option= Double Hit Enable/Disable
7. option= Daylight Saving Enable/Disable
3=ON
5=ON
7=ON
43 IP
Look at pg.
34 for SPT
10 02
Output Types
1.option= ARM NC/NO (ON= NC, OFF= NO)
2. option= PGM1 NC/NO
3. option= PGM2 NC/NO
5. option= SRN NC/NO (positive/negative trigger)
1=OFF
2=OFF
3=OFF
5=OFF
43 IP
10 03
Automatic Bypassed
Partitions
1. option= A Partition
2. option= B Partition
3. option= C Partition
4. option= D Partition
-
44 IP
Look at pg.
34 for SPT
10 04
Reset Types
1. option= Reset Codes
2. option= Reset Panel Settings
-
44 IP, MP
IP
ADDRESS
FUNCTION
VALUE
DEFAULT
VALUE
ENTERED
VALUE
PAGE &
PROGRAM
IP:Installer
MP:Master
10 06
Reset Enable/Disable
1. option= Resetting Codes Enable/Disable
2. option= Resetting Panel Settings Enable/Disable
1= ON
2= ON
44 IP
10 07
ARM Partitions
1. option = A Partition
2. option = B Partition
3. option = C Partition
4. option = D Partition
A, B, C, D
45 IP
Look at pg.
34 for SPT
10 08
AC Fail Call Delay
0~60 minutes
15
45 IP
10 09
Cross Zone Timer
0~255 seconds
60
45 IP
11 01
Siren Partitions
1. option = A Partition
2. option = B Partition
3. option = C Partition
4. option = D Partition
A, B, C, D
46 IP
Look at pg.
34 for SPT
11 02
Siren Cut off Time
2~255 minutes
5 minutes
46 IP
12 01
Automatic ARM Partitions
1. option= A Partition
2. option= B Partition Automatic Arm is disabled
3. option= C Partition if no partition is selected
4. option= D Partition
No
partition is
selected
46 IP, MP
Look at pg.
34 for SPT
12 02
Automatic ARM Days
1. Option = Monday 5. option = Friday
2. Option = Tuesday 6. option = Saturday
3. Option = Wednesday 7. option = Sunday
All days
are
47 IP, MP
