Teknim VAP404 - Page 20

TD-1/07-008
20 / 83
4. option = Thursday
selected
12 03
Automatic ARM Time
HH MM HH= hour, MM= minute
00:00
47 IP, MP
12 04
Automatic Disarm Partitions
1. option= A Partition
2. option= B Partition Automatic Disarm is
3. option= C Partition disabled if no partition is
4. option= D Partition selected.
No
partition is
selected
47 IP, MP
Look at pg.
34 for SPT
12 05
Automatic Disarm Days
1. option = Monday 5. option = Friday
2. option = Tuesday 6. option = Saturday
3. option = Wednesday 7. option = Sunday
4. option = Thursday
All days
are
selected
48 IP, MP
12 06
Automatic Disarm Time
HH MM HH=hour, MM=minute
00:00
48 IP, MP
12 07
Automatic Arm Partitions on
no Activity
1. option= A Partition
2. option= B Partition This feature is disabled,
3. option= C Partition if no partition is selected.
4. option= D Partition
No
partition is
selected
48 IP
Look at pg.
34 for SPT
12 08
No Activity Time
(for Automatic Arm)
5~255 minutes
30 minutes
49 IP
13 01
13 03
13 05
13 07
13 09
13 11
13 13
13 15
PGM1 Usage Type
PGM2 Usage Type
PGM3 Usage Type(*)
PGM4 Usage Type
PGM5 Usage Type
PGM6 Usage Type
PGM7 Usage Type
PGM8 Usage Type
0 = Free
1 = PGM is active while selected zones are active
2 = PGM is active while selected zones are active
3 = PGM is activated when selected partitions are armed.
4 = Fire siren
5 = PGM resets fire detector when fire alarm is ended.
6 = Siren
7 = PGM is active on selected troubles
8 = PGM controls magnetic door (Access Control).
9 = Timer controls PGM (**)
10 = Random PGM ON/OFF
11= On arm
12= On disarm
13= Control with remote control button
14= Alarm type indicator
(*) VAP404 has 3 onboard PGM outputs. You can get 4 PGM
outputs by using TRM904 module, or can get 8 PGM outputs
by using 2 TRM904 module together. Look at TRM904 guide
for detailed description.
(**) 9. option is valid for the first four PGM’s(PGM1 to PGM4)
0=Closed
49, 50 IP
Look at pg.
34 for SPT
13 02
13 04
13 06
13 08
13 10
13 12
13 14
13 16
PGM1 Parameter
PGM2 Parameter
PGM3 Parameter (*)
PGM4 Paremeter
PGM5 Paremeter
PGM6 Paremeter
PGM7 Paremeter
PGM8 Paremeter
0~255,
(*) VAP404 PLUS has 2 PGM outputs. You can get 4 PGM
outputs by using TRM904 module, or can get 8 PGM outputs
by using 2 TRM904 module together. Look at TRM904 guide
for detailed description.
0
49 IP
50
ADDRESS
FUNCTION
VALUE
DEFAULT
VALUE
ENTERED
VALUE
PAGE &
PROGRAM
IP:Installer
MP:Master
14 01
14 04
Timer1 Setting
Timer2 Setting
1. option= PGM1 Control Enable/Disable
2. option= PGM1 State (ON/OFF)
3. option= PGM2 Control Enable/Disable
4. option= PGM2 State (ON/OFF)
5. option= PGM3 Control Enable/Disable(*)
6. option= PGM3 State (ON/OFF)
7. option= PGM4 Control Enable/Disable
8. option= PGM4 State (ON/OFF)
(*) VAP408 PLUS has 2 PGM outputs. You can get 4 PGM
outputs by using TRM904 module, or can get 8 PGM outputs
by using 2 TRM904 module together. Look at TRM904 guide
for detailed description.
-
51 IP, MP
52
14 02
14 05
Timer1 Days
Timer2 Days
1. option = Monday 5. option = Friday
2. option = Tuesday 6. option = Saturday
3. option = Wednesday 7. option = Sunday
4. option = Thursday
All days
are
selected
52 IP, MP
14 03
14 06
Time of Timer1
Time of Timer2
HH MM HH=hour, MM=minute
00:00
52 IP, MP
53
15 01
Remote Control
(ON/OFF)
1. option= Remote control by phone Enable/Disable
2. option= Remote control by PC(modem) Enable/Disable*
* This feature is only active if modem module is connected
to VAP404 panel.
Closed
53 IP, MP
