Tektronix Keithley 4200A-SCS - Getting Started; Front Panel Overview

In this section:
Front panel overview ................................................................ 2-1
Rear panel overview ................................................................ 2-4
Installation ................................................................................ 2-6
Front panel overview
Many controls and interfaces are on the front panel of the 4200A-SCS Parameter Analyzer. The next
figure shows the front panel of the 4200A-SCS. The components are summarized following the figure.
Figure 1: 4200A-SCS front panel
