Section 2: Getting started 4200A-SCS Parameter Analyzer User's Manual
2-6 4200A-900-01 Rev. D/April 2020
Installation
This section contains information about handling and installing the 4200A-SCS:
• Locating the system: Describes how to select the best operating environment location for your
4200A-SCS.
• Basic system connections: Explains how to connect the grounding cable, LAN cable,
GPIB-compatible instruments, and the safety interlock to the 4200A-SCS.
• SMU connections: Describes how to make SMU connections to the device under test (DUT).
• Powering the 4200A-SCS: Describes line power requirements for the 4200A-SCS, and shows
how to connect the power line cord.
When you start one of the Clarius
+
applications for the first time, you must agree to the
license agreement before continuing. If you do not respond with "Yes", your system will not
function until you reinstall the software.
The condensed installation information in this section is intended to get your 4200A-SCS set up and
ready to turn on as quickly as possible. Detailed information on connections is provided in the Model
4200A-SCS Reference Manual.
Locating the system
Locate the 4200A-SCS so that it will operate within the following ambient temperature and humidity
limits:
• Temperature: +10 °C to +40 °C
• Relative humidity: 5% to 80%, non-condensing
SMU and preamplifier accuracy specifications are based on operation at 23 °C ±5 °C and between
5% and 60% relative humidity. See the 4200A-SCS datasheet at the Keithley Instruments website
(tek.com/keithley) for derating factors outside these ranges.
