Tektronix Keithley 4200A-SCS - Add a Device

4200A-SCS Parameter Analyzer User's Manual Section 3: Create a new project and test
4200A-900-01 Rev. D/April 2020 3-5
Add a device
Tests must be placed in the project under a device.
To add a device:
1. Select Devices.
2. From the Filters pane, select the 3 under the Terminals heading and Transistor under the Device
Type option.
Figure 18: Searching for a device using Filters
3. Select the MOSFET, n-type, 3 terminal (3terminal-n-fet) device.
4. Select Add to copy it to the project tree.
