Get Acquainted w
ith the Instrument
16. Run/Stop. Push to start or stop
acquisitions.
17. Single. Push to make a single
acquisition
.
18. Autoset. Push to automatically set the
vertical, h
orizontal, and trigger controls
for a usable, stable display.
19. Trigger Lev
el. Turn to adjust the trigger
level.
Push this button to set the trigger level to
the midpoi
nt of the w aveform.
20. Force Trig . Push to force an immediate
trigger event.
21. Vertical Position. Turn to adjust the
vertical position of the corresponding
wavefor
m. Push Fine to make smaller
adjustments.
22. 1, 2, 3, 4
. Push to display or remove
the corresponding waveform from the
display and access the vertical menu.
23. Vertic
al Scale. Turn to adjust the
vertical scale factor of the corresponding
waveform (volts/division).
24. Print. Push to print a screen image using
the printer selected in the Utility menu.
(See p
age 132, Printing a Hard Copy.)
25. Powe
r switch. Push to power on or off
the instrument.
MSO3000 and DPO 3000 Series Oscilloscopes User Manual 35
