Acquire the Sign
al
Use the side menu buttons to define
parameters for the inputs, such as speci fic
signals to an a
nalog or digital channel.
Define
Inputs
If you select Parallel, push the side menu
button to ena
ble or disable Clocked Data.
Clocked
Data
Yes|
No
Push C lock Edg e on the side menu to select
the edge on w hich to clock data: rising edge,
falling edg
e, or both edges.
Clock
Edge
Turn multipurpose knob a to se lect the
Number of Data Bits in the parallel bus.
Number of
Data Bits
(a) 16
Turn multi
purpose knob a to select the
desired bit to define.
Turn multipurpose knob b to select the
desired a
nalog or digital channel as the
source for the bit.
Define Bits
(a) Bit 15
(b) D15
4. Push Thresholds.
Bus B1
Parall
el
Define
Inputs
Thresholds B1 Label
Paralle
l
Bus
Display
Event
Table
You c an set the threshold for all c hannels in
the par
allel or serial bus from a list of preset
values. The preset values vary, depending
on the bus type.
Altern
ately, you can set the threshold to a
specific value for the signals that make up the
parallel or serial bus. To do so, push Select
on the
side menu and turn multipurpose knob
a to select a Bit or a Channel number (Signal
name).
Then, turn multipurpose knob b to define the
voltage level above which the oscilloscope
treats the signal as a logic high and below
which as a logic low.
NOTE. Some buses use two thresholds per
channel.
62 MSO4000B and DPO 4000B Series Oscilloscopes User Manual
