Measurement Description
TIE Time Interval Error. The difference in time between an edge in the source waveform and the
corresponding edge in a recovered reference clock signal.
The measurement is taken on each waveform edge.
TJ@BER Total error at a specified bit error rate. The predicated peak-to-peak amplitude of jitter that will
only be exceeded with a probability equal to the bit error rate.
The measurement is taken on the entire record.
Eye Measurements panel (optional).
Measurement Description
Eye Height The minimum vertical eye opening at the center of the recovered unit interval.
The measurement is taken on the entire waveform record.
Eye High The amplitude of a high (one) bit measured at a specified location within the recovered unit
interval.
The measurement is taken on each high bit in the waveform record.
Eye Low The amplitude of a low (zero) bit measured at a specified location within the recovered unit
interval.
The measurement is taken on each low bit in the waveform record.
Eye Width The minimum horizontal eye opening at the center of the recovered unit interval.
The measurement is taken on the entire waveform record.
EyeHeight@BER The predicted vertical eye opening that will be violated with a probability equal to the bit error
rate.
The measurement is taken on the entire waveform record.
EyeWidth@BER The predicted horizontal eye opening that will be violated with a probability equal to the bit error
rate.
The measurement is taken on the entire waveform record.
Q-Factor The ratio of the vertical eye opening to RMS vertical noise measured at a specified location in
the recovered unit interval.
The measurement is taken on the entire waveform record.
Menus and dialog boxes
MSO54, MSO56, MSO58, MSO58LP, MSO64 Help 159
