CAN serial bus search configuration menu
Use the CAN Search configuration menu to define conditions to search for and mark on an CAN bus waveform. You can have
multiple searches on the same bus.
NOTE. Requires option SRAUTO.
Field or control Description
Display Enables or disables displaying search marks on this search.
Stop Acquisition if Event
Found
Stops input acquisition when the search event occurs. Default is not enabled.
Source Select the CAN bus that you want to search.
Mark On Select the type of information for which to search.
Frame Type Sets the frame type for which to search.
Only available when Mark On = Type of Frame.
BRS Bits Sets the BRS bits state for which to search.
Only available when Mark On = FD Bits.
ESI Bits Sets the ESI bits state for which to search.
Only available when Mark On = FD Bits.
Direction Sets the transfer direction for which to search.
Only available when Mark On = Identifier.
Identifier Format Sets the identifier for Standard (11-bit) or Extended (29-bit for CAN 2.0B) length.
Only available when Mark On = Identifier or ID & Data.
Identifier Sets the identifier pattern for which to search. The number of bits shown depends on the
Identifier Format setting.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Identifier or ID & Data.
Data Bytes Sets the number of data bytes for which to search (one to eight bytes). Use the A knob to
change the value.
Only available when Mark On = Data or ID & Data.
Data Offset Sets the data offset value. Use the A knob to change the value.
Only available when Mark On = Data or ID & Data.
Data Sets the data pattern for which to search. The number of bits shown depends on the Data
Bytes setting.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Data or ID & Data.
Menus and dialog boxes
234 MSO54, MSO56, MSO58, MSO58LP, MSO64 Help
