Field or control Description
Bandwidth Limit Tap to select the bandwidth limit from the drop-down list.
Bandwidth Filter Optimized
For
Tap to select a bandwidth filter that is optimized for flatness or step response.
Flatness selects a brick-wall filter optimized for flatness within band with a sharp rolloff.
Flatness filtering is not compatible with Peak Detect and Envelope acquisition modes.
Step Response selects a Bessel-Thompson filter that minimizes overshoot with a gradual
rolloff.
High Res acquisition mode requires Flatness filtering.
This selection is only available on 6 Series MSO instruments.
Other settings panels
Probe Setup Use to see probe information, check the probe compensation status, compensate the probe, or
restore the factory defaults
.
See Probe Setup panel (Channel configuration menu) on page 265.
See Probe Compensation configuration menu (analog channels Probe Setup panel) on
page 267.
See Unsupported Probe dialog on page 267.
Other Use to adjust signal delay to align signal arrival at the oscilloscope between probes and/or
cables.
See Other panel (Channel configuration menu) on page 268.
Probe Setup panel (Channel configuration menu)
Use the Channel configuration menu Probe Setup panel to see probe information, check the probe compensation status,
compensate the probe, or restore the factory defaults.
To open the Probe Setup panel:
1. Double-tap an analog Channel badge on the Settings bar to open the Channel configuration menu.
2. Tap the Probe Setup panel.
Menus and dialog boxes
MSO54, MSO56, MSO58, MSO58LP, MSO64 Help 265
