I2C serial bus trigger settings panel
NOTE. Requires option SREMBD.
Field or control Description
Source Select the I
2
C bus on which to trigger.
Trigger On Select the type of information on which to trigger.
Direction Sets the transfer direction on which to trigger (Read, Write, Either).
Available when Trigger On = Address.
Addressing Mode Sets the slave device address length (7 bits or 10 bits long).
Available when Trigger On = Address or Address & Data.
Address Sets the address pattern on which to trigger. The number of bits shown depends on the
Address Mode setting.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Address or Address & Data.
Data Bytes Sets the number of data bytes on which to trigger (one to five bytes). Use the A knob to change
the value.
Available when Trigger On = Data or Address & Data.
Data Sets the data pattern on which to trigger. The number of bits shown depends on the Data Bytes
setting.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Data or Address & Data.
A, B knob controls Use the A knob to select (highlight) the digit(s) to change.
Use the B knob to change the value of the digit(s). Or double-tap on the field and use the virtual
keypad to enter values.
Menus and dialog boxes
356 MSO54, MSO56, MSO58, MSO58LP, MSO64 Help
